EVAL - ADM1023

Next Generation upgrade to the ADM1021
On-Chip and Remote Temperature Sensing
Offset Registers for System Calibration
1 Accuracy and Resolution on Local Channel
0.125 Resolution/1 Accuracy on Remote Channel
Programmable Over/Under Temperature Limits
Programmable Conversion Rate
2-Wire SMBus Serial Interface
Supports System Management Bus (SMBus™) Alert
160mA Max Operating Current
3mA Standby Current
3V to 5.5V Supply
Small 16-Lead QSOP Package

The ADM1023 Evaluation Board allows the ADM1023 microprocessor system temperature IC to be quickly and easily evaluated using a personal computer. Using the evaluation board and its accompanying software the ADM1023 can be interfaced to any personal computerrunning Windows™ 95 or Windows™ 98, via the computer's parallel printer port.

The ADM1023 evaluation board allows the input and output functions of the ADM1023 to be exercised without the need for external components. The software allows control and monitoring of the ADM1023's internal registers.
