ES2C-13-F

Rectifiers 150V 2A

product image

ES2C-13-F Picture
See larger image
SeekIC No. : 00175195 Detail

ES2C-13-F: Rectifiers 150V 2A

ES2C-13-F Data Sheet

floor Price/Ceiling Price

US $ .14~.17 / Piece | Get Latest Price
Part Number:
ES2C-13-F
Mfg:
Diodes Inc.
Supply Ability:
5000

Price Break

  • Qty
  • 0~1900
  • 1900~3000
  • 3000~6000
  • 6000~12000
  • Unit Price
  • $.17
  • $.16
  • $.15
  • $.14
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Product : Ultra Fast Recovery Rectifiers Configuration : Single
Reverse Voltage : 150 V Forward Voltage Drop : 0.92 V
Recovery Time : 25 ns Forward Continuous Current : 2 A
Max Surge Current : 50 A Reverse Current IR : 5 uA
Mounting Style : SMD/SMT Package / Case : SMB
Packaging : Reel

Description

Product : Ultra Fast Recovery Rectifiers
Mounting Style : SMD/SMT
Packaging : Reel
Configuration : Single
Reverse Current IR : 5 uA
Max Surge Current : 50 A
Recovery Time : 25 ns
Forward Continuous Current : 2 A
Reverse Voltage : 150 V
Package / Case : SMB
Forward Voltage Drop : 0.92 V


Parameters:

Technical/Catalog InformationES2C-13-F
VendorDiodes Inc (VA)
CategoryDiscrete Semiconductor Products
Diode Type Standard
Voltage - DC Reverse (Vr) (Max)150V
Current - Average Rectified (Io)2A
Voltage - Forward (Vf) (Max) @ If920mV @ 2A
Reverse Recovery Time (trr)25ns
Current - Reverse Leakage @ Vr5A @ 150V
SpeedFast Recovery =< 500ns, > 200mA (Io)
Mounting TypeSurface Mount
Package / CaseDO-214AA, SMB
PackagingCut Tape (CT)
Capacitance @ Vr, F25pF @ 4V, 1MHz
Lead Free StatusLead Free Compliant by Exemption
RoHS StatusRoHS Compliant
Other Names ES2C 13 F
ES2C13F
ES2C FDICT ND
ES2CFDICTND
ES2C-FDICT
