ES1B-13

Rectifiers 100V 1A

product image

ES1B-13 Picture
See larger image
SeekIC No. : 00184284 Detail

ES1B-13: Rectifiers 100V 1A

ES1B-13 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
ES1B-13
Mfg:
Diodes Inc.
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/5/31

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Product : Ultra Fast Recovery Rectifiers Configuration : Single
Reverse Voltage : 100 V Forward Voltage Drop : 0.92 V
Recovery Time : 25 ns Forward Continuous Current : 1 A
Max Surge Current : 30 A Reverse Current IR : 5 uA
Mounting Style : SMD/SMT Package / Case : SMA
Packaging : Reel

Description

Product : Ultra Fast Recovery Rectifiers
Mounting Style : SMD/SMT
Forward Continuous Current : 1 A
Max Surge Current : 30 A
Packaging : Reel
Configuration : Single
Reverse Current IR : 5 uA
Recovery Time : 25 ns
Package / Case : SMA
Reverse Voltage : 100 V
Forward Voltage Drop : 0.92 V


Parameters:

Technical/Catalog InformationES1B-13
VendorDiodes Inc
CategoryDiscrete Semiconductor Products
Diode Type Standard
Voltage - DC Reverse (Vr) (Max)100V
Current - Average Rectified (Io)1A
Voltage - Forward (Vf) (Max) @ If920mV @ 1A
Reverse Recovery Time (trr)25ns
Current - Reverse Leakage @ Vr5A @ 100V
SpeedFast Recovery =< 500ns, > 200mA (Io)
Mounting TypeSurface Mount
Package / CaseDO-214AC, SMA
PackagingTape & Reel (TR)
Capacitance @ Vr, F10pF @ 4V, 1MHz
Lead Free StatusContains Lead
RoHS StatusRoHS Non-Compliant
Other Names ES1B 13
ES1B13
ES1BDITR ND
ES1BDITRND
ES1BDITR
