Programmable Type: In System Programmable
Delay Time tpd(1) Max: 10.0ns
Voltage Supply - Internal: 3 V ~ 3.6 V
Mounting Type: Surface Mount
Packaging: Tray
Number of Logic Elements/Blocks: 4
Number of Macrocells: 64
Operating Temperature: 0°C ~ 70°C
Supplier Device Package: 100-TQFP (14x14)
Package / Case: 100-TQFP
Manufacturer: Altera
Series: MAX® 3000A
Number of Gates: 1250
Number of I /O: 66
DescriptionThe EPM3064ATC100-10 is one member of the EPM3128 family which is designed as the lowcost, highperformance device that contains 32 to 512 macro-cells, combined into groups of 16 macrocells called logic array blocks (LABs). This device has an enhanced ISP algorithm for faster programming and also offer an ISP_Done bit that ensures safe operation when insystem programming is interrupted.
Features of the EPM3064ATC100-10 are:(1)programmable interconnect array (PIA) continuous routing structure for fast, predictable performance;(2)hot-socketing support;(3)4.5ns pintopin logic delays with counter frequencies of up to 227.3 MHz;(4)highdensity PLDs ranging from 600 to 10,000 usable gates;(5)builtin boundary-scan test (BST) circuitry compliant with IEEE Std. 1149.1-1990;(6)highperformance, lowcost CMOS EEPROMbased programmable logic devices (PLDs) built on a MAX architecture.
The absolute maximum ratings of the EPM3064ATC100-10 can be summarized as:(1)supply voltage:-0.5 to 4.6 V;(2)DC input voltage:-2.0 to 5.75 V;(3)DC output current, per pin:-25 to 25 mA;(4)storage temperature:-65 to 150 °C;(5)ambient temperature:-65 to 135 °C;(6)junction temperature:135 °C. If you want to know more information such as the electrical characteristics about the EPM3064ATC100-10, please download the datasheet in www.seekic.com or www.chinaicmart.com .
Parameters: | Technical/Catalog Information | EPM3064ATC100-10 |
| Vendor | Altera |
| Category | Integrated Circuits (ICs) |
| Programmable Type | In System Programmable |
| Number of Macrocells | 64 |
| Number of I /O | 66 |
| Number of Logic Blocks/Elements | 4 |
| Operating Temperature | 0°C ~ 70°C |
| Package / Case | 100-TQFP |
| Features | - |
| Voltage | 3.0 V ~ 3.6 V |
| Memory Type | EEPROM |
| Delay Time tpd(1) Max | 10.0nS |
| Packaging | Tray |
| Lead Free Status | Contains Lead |
| RoHS Status | RoHS Non-Compliant |
| Other Names | EPM3064ATC100 10
EPM3064ATC10010
544 1156 ND
5441156ND
544-1156
|
