640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> Nominal Frequency | 1.000MHz to 125.000MHz |
The specified reference or "center" frequency of the oscillator. Typically specified in megahertz (MHz)or kilohertz (kHz). |
| 640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> |
640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> Frequency Tolerance/Stability | (Inclusive of all conditions: Calibration Tolerance at 25°C, Frequency Stability over the Operating Temperature Range, Supply Voltage Change, Output Load Change, First Year Aging at 25°C, Shock, and Vibration.)
±100ppm Maximum (Standard)
±50ppm Maximum |
This "inclusive" specification is the amount of frequency deviationfrom the center frequency associated with a set of operatingconditions. These conditions include: Operating Temperature Range,Supply Voltage, and Output Load. This parameter is specified with amaximum and minimum frequency deviation, expressed in percent (%)or parts per million (ppm). |
| 640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> |
640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> Operating Temperature Range | -20°C to +70°C (Standard)
-40°C to +85°C |
The maximum and minimum temperatures that the oscillator device can be exposed to during oscillation. Over thistemperature range, all of the specified device operatingparameters are guaranteed. |
| 640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> |
640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> Supply Voltage (VDD) | 5.0VDC ±10% |
The DC input voltage necessary for oscillator operation, specified involts. |
| 640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> |
640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> Input Current | 45mA Maximum (Unloaded) |
The amount of current consumption by an oscillator from the powersupply, typically specified in milliamps (mA). |
| 640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> |
| Disable Current (Tri-State Option) | 30mA Maximum (Pin 1 = Ground) |
| 640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> |
| Standby Current (Power Down Option) | 50µA Maximum (Pin 1 = Ground) |
| 640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> |
640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> Output Voltage Logic High (VOH) | 2.4VDC Minimum with TTL Load (IOH=-16mA)
VDD-0.4VDC Minimum with HCMOS Load (IOH=-16mA) |
Defined as the Output Voltage Logic High or "Logic 1" (Figure 1 in oscillator glossary of terms). |
| 640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> |
640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> Output Voltage Logic Low (VOL) | 0.4VDC Maximum (IOL=+16mA) |
Defined as the Output Voltage Logic Low or "Logic 0" (Figure 1 in oscillator glossary of terms). |
| 640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> |
640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> Duty Cycle | Measured at 1.4VDC with TTL Load or at 50% of waveform with HCMOS load. 50 ±10(%) (Standard) 50 ±5(%) (Optional) available from 1 to 27MHz with TTL load or from 1 to 50MHz with HCMOS load |
The measure of output waveform uniformity. This term, also referredto as symmetry, is a measurement of the time that the outputwaveform is in a logic high state, expressed as a percentage (%).This parameter is measured at a specified voltage threshold or at apercentage of the output waveform amplitude (Figure 1 in the oscillator glossary of terms). |
| 640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> |
640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> Rise Time/Fall Time | Measured over 0.8VDC to 2.0VDC with TTL load or from 20% to 80% of waveform with HCMOS load. 4nSec Maximum |
The Rise Time, measured in nanoseconds (nSec), is defined as thetransition time from an output logic low to an output logic high.Conversely, the Fall Time, also measured in nanoseconds (nSec), isdefined as the transition time from an output logic high to an outputlogic low. This transition time is measured at specified voltagethresholds or at specified percentages of the output waveformamplitude (Figure 1 in the oscillator glossary of terms). |
| 640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> |
640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> Load Drive Capability | 50pF HCMOS Load Maximum from 1.000MHz to 50.000MHz
15pF HCMOS Load Maximum from 50.001MHz to 125.000MHz 10 TTL Load Maximum from 1.000MHz to 40.000MHz
5 TTL Load Maximum from 40.001MHz to 125.000MHz |
The maximum load the oscillator can drive specified in terms of thenumber of gates or the type of load circuit (Figures 2, 3 and 4 in oscillator glossary of terms). |
| 640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> |
640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> Aging (at 25°C) | ±5ppm/year Maximum |
The systematic change in frequency with time due to internal changes in the crystal. Aging is often expressed as a maximum value in parts per million per year (ppm/yr). The rate of aging is typically greatest during the first 30 to 60 days after which time the aging rate decreases. The following factors effect crystal aging: adsorption and desorption of contamination on the surfaces of the quartz, stress relief of the mounting and bonding structures, material outgassing, and seal integrity. |
| 640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> |
640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> Storage Temperature | -55°C to +125°C |
The minimum and maximum temperatures that the device can be stored or exposed to when in a non-oscillation state. After exposing or storing the device at the minimum or maximum temperatures for a length of time, all of the operating specifications are guaranteed over the specified Operating Temperature Range. |
| 640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> |
| Output Control Function | Tri-State Enable High or Power Down |
| 640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> |
| Input Voltage | VIH of 2.0VDC or greater or No Connection to enable output. VIL of 0.8VDC or less to disable output (High Impedance State for Tri-State. Logic Low for Power Down). |
| 640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> |
| Jitter | | Absolute: | ±250pSec Maximum, ±100pSec Typical less than or equal to 33MHz
±100pSec Maximum, ±50pSec Typical above 33MHz | | One Sigma: | ±50pSec Maximum less than or equal to 33MHz
±30pSec Maximum greater than 33MHz | |
| 640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> |
640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> Start Up Time | 10mSec Maximum |
The specified time from oscillator power-up to the time the oscillatorreaches steady state oscillation. |
| 640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram"> |
EP25 Data Sheet
