EM1537

DescriptionThe EM1537 is an integrated circuit in a low power CMOS technology for battery operated wristwatches with bipolar stepping motors. Time base is a 32 kHz crystal oscillator. It has a very low current consumption of typ. 100 nA in awide voltage range of 1.2 to 3.6 Volt.The EM1537 IC is av...

product image

EM1537  Picture
See larger image
SeekIC No. : 004335864 Detail

EM1537 : DescriptionThe EM1537 is an integrated circuit in a low power CMOS technology for battery operated wristwatches with bipolar stepping motors. Time base is a 32 kHz crystal oscillator. It has a very ...

EM1537  Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
EM1537
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/5/31

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Description

The EM1537 is an integrated circuit in a low power CMOS technology for battery operated wristwatches with bipolar stepping motors. Time base is a 32 kHz crystal oscillator. It has a very low current consumption of typ. 100 nA in a
wide voltage range of 1.2 to 3.6 Volt.

The EM1537 IC is available in two voltage ranges - 1.2 to 1.8 Volt and 1.8 to 3.6 V.

Motor pulse width is programmable from 0.098 ms to 14.65 ms in steps of 0.98 ms by metal mask.
Motor period is programmable from 2 x 1s to 2 x 60 s in steps of 1 s selectable by metal mask.
Motor pulse chopping is programmable from 1/8 to 8/8 in steps of 1/8 with chopping frequencies of 1024 Hz or 2048 Hz selectable by metal mask.
Motor period in Motor test mode is selectable 2 x 31.25 ms or 2 x 62.5 ms by metal mask.

Input and output capacitors EM1537 are integrated on chip and also programmable by metal mask.

With a fully debounced RESET pad, the motor EM1537 can be stopped.

A multi-functional bi-directional pad MTEST acts as output for a 32 Hz or 512 Hz for frequency tuning - if open, or if connected to Vp accelerates the motor period by a factor of 16 or 32.
