ELJ-FA820JF

Power Inductors 82UH +/-5% INDUCTOR

product image

ELJ-FA820JF Picture
See larger image
SeekIC No. : 001177385 Detail

ELJ-FA820JF: Power Inductors 82UH +/-5% INDUCTOR

ELJ-FA820JF Data Sheet

floor Price/Ceiling Price

US $ .12~.16 / Piece | Get Latest Price
Part Number:
ELJ-FA820JF
Mfg:
Panasonic Electronic Components
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~250
  • Unit Price
  • $.16
  • $.14
  • $.13
  • $.12
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/6/9

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Inductance : 82 uH Tolerance : 5 %
Maximum DC Current : 60 mAmps Maximum DC Resistance : 10 Ohms
Operating Temperature Range : - 20 C to + 85 C Self Resonant Frequency : 10 MHz
Q Minimum : 30 Dimensions : 2.5 mm W x 3.2 mm L x 2.2 mm H
Shielding : Unshielded Termination Style : SMD/SMT
Package / Case : 1210 (3225 metric)

Description

Operating Temperature Range : - 20 C to + 85 C
Termination Style : SMD/SMT
Shielding : Unshielded
Tolerance : 5 %
Self Resonant Frequency : 10 MHz
Inductance : 82 uH
Q Minimum : 30
Dimensions : 2.5 mm W x 3.2 mm L x 2.2 mm H
Package / Case : 1210 (3225 metric)
Maximum DC Resistance : 10 Ohms
Maximum DC Current : 60 mAmps


Parameters:

Technical/Catalog InformationELJ-FA820JF
VendorPanasonic - ECG (VA)
CategoryInductors, Coils, Chokes
Inductance82H
Tolerance±5%
Package / Case1210 (3225 metric)
PackagingDigi-Reel?
Type-
Current 60mA
Mounting TypeSurface Mount
Q @ Freq30 @ 2.52MHz
Self Resonant Freq10MHz
DC Resistance (DCR)10.00 Ohm Max
Shielding-
ApplicationsGeneral Purpose
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names ELJ FA820JF
ELJFA820JF
PCD1844DKR ND
PCD1844DKRND
PCD1844DKR
