EL2001C

Features: ·1.3 mA supply current· 70 MHz bandwidth· 2000 V/ms slew rate· Low bias current, 1 mA typical· 100 mA output current· Short circuit protected· Low cost· Stable with capacitive loads· Wide supply range g5V to g15V· No thermal runawayApplication· Op amp output current booster· Cable/line d...

product image

EL2001C Picture
See larger image
SeekIC No. : 004335108 Detail

EL2001C: Features: ·1.3 mA supply current· 70 MHz bandwidth· 2000 V/ms slew rate· Low bias current, 1 mA typical· 100 mA output current· Short circuit protected· Low cost· Stable with capacitive loads· Wide ...

EL2001C Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
EL2001C
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/24

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

·1.3 mA supply current
· 70 MHz bandwidth
· 2000 V/ms slew rate
· Low bias current, 1 mA typical
· 100 mA output current
· Short circuit protected
· Low cost
· Stable with capacitive loads
· Wide supply range g5V to g15V
· No thermal runaway


Application

· Op amp output current booster
· Cable/line driver
· A/D input buffer
· Low standby current systems


Pinout

Connection Diagram


Specifications

VS               Supply Voltage (Va bVb) .........................±18V or 36V
VIN             Input Voltage (Note 1)................................±15V or VS
IIN              Input Current (Note 1) ....................................±50 mA
PD               Power Dissipation (Note 2........................)See Curves
                   Output Short Circuit
                   Duration (Note 3) ......................................Continuous
TA               Operating Temperature Range
                   EL2001AC/EL2001C................................ 0 to +75
TJ                Operating Junction Temperature .......................150
TST             Storage Temperature ..........................-65 to +150


Description

The EL2001 is a low cost monolithic, high slew rate, buffer amplifier. Built using the Elantec monolithic Complementary Bipolar process, this patented buffer has a b3 dB bandwidth of 70 MHz, and delivers 100 mA, yet draws only 1.3 mA of supply current. It typically operates from g15V power supplies but will work with as little as g5V.

This EL2001 high speed buffer may be used in a wide variety of applications in military, video and medical systems. A typical example is a general purpose op amp output current booster where the buffer must have sufficiently high bandwidth and low phase shift at the maximum frequency of the op amp.

Elantec's products EL2001 and facilities comply with MIL-I-45208A, and other applicable quality specifications. For information on Elantec's processing, see the Elantec document, QRA-1: Elantec's Processing, Monolithic Integrated Circuits.
