See larger image

SeekIC No. : 002906389 Detail

ECE-T1CP104EA: CAP ALUM 100000UF 16V 20% SNAP

ECE-T1CP104EA Data Sheet

US $ 3.65~7.01 / Piece | Get Latest Price

Part Number:: ECE-T1CP104EA
Mfg:
Supply Ability:: 5000

Price Break

Qty
0~1
1~50
50~200
200~1000

Unit Price
$7.01
$5.89
$4.09
$3.65

Processing time
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/12/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

ECE-0188-HOLDING-FIX evaluate
US $244.97 - 271.69 / Piece

Hand Tools
ECE-A0GKA101 evaluate
US $.03 - .04 / Piece

Aluminum Electrolytic Capacitors - Leaded 4VDC 100uF SU BI-POL
ECE-A0GKA101B evaluate
US $.03 - .04 / Piece

Aluminum Electrolytic Capacitors - Leaded 4VDC 100uF SU BI-POL

Product Details

Quick Details

Series:	T-UP	Manufacturer:	Panasonic Electronic Components
Capacitance:	100000µF	Dimensions :	196 mm L x 12.5 mm W
Voltage Rating:	16V	Tolerance:	±20%
Lifetime @ Temp.:	3000 Hrs @ 85°C	Operating Temperature:	-40°C ~ 85°C
Features:	General Purpose	Ripple Current:	11A
ESR (Equivalent Series Resistance):	15 mOhm	Impedance:	-
Mounting Type:	Through Hole	Package / Case:	Radial, Can - Snap-In - 4 Lead
Size / Dimension:	1.378" Dia (35.00mm)	Height - Seated (Max):	3.150" (80.00mm)
Lead Spacing:	0.886" (22.50mm)	Surface Mount Land Size:	-

Description

Manufacturer: Panasonic Electronic Components
Tolerance: ±20%
Operating Temperature: -40°C ~ 85°C
Features: General Purpose
Impedance: -
Mounting Type: Through Hole
Surface Mount Land Size: -
Voltage Rating: 16V
Packaging: Bulk
ESR (Equivalent Series Resistance): 15 mOhm
Lifetime @ Temp.: 3000 Hrs @ 85°C
Size / Dimension: 1.378" Dia (35.00mm)
Series: T-UP
Package / Case: Radial, Can - Snap-In - 4 Lead
Lead Spacing: 0.886" (22.50mm)
Height - Seated (Max): 3.150" (80.00mm)
Capacitance: 100000µF
Ripple Current: 11A

Parameters:

Technical/Catalog Information	ECE-T1CP104EA
Vendor	Panasonic - ECG
Category	Capacitors
Capacitance	100000F
ESR (Equivalent Series Resistance)	19.0 mOhm
Features	General Purpose
Lifetime @ Temp.	3000 Hrs @ 85°C
Maximum Temperature	-40°C ~ 85°C
Size / Dimension	1.378" Dia x 3.150" H (35.00mm x 80.00mm)
Lead Spacing	0.886" (22.50mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial (Snap-In)
Packaging	Bulk
Tolerance	±20%
Voltage Rating	16V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	ECE T1CP104EA ECET1CP104EA P10002 ND P10002ND P10002
