See larger image

SeekIC No. : 003124943 Detail

EBC36DREF-S734: CONN EDGECARD 72POS .100 EYELET

EBC36DREF-S734 Data Sheet

US $ 5.52~5.52 / Piece | Get Latest Price

Part Number:: EBC36DREF-S734
Mfg:
Supply Ability:: 5000

Price Break

Qty
0~10

Unit Price
$5.52

Processing time
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/11/24

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

EBC30DCAD evaluate
US $4.3 - 4.3 / Piece

CONN EDGECARD 60POS R/A .100 SLD
EBC30DCAH evaluate
US $4.3 - 4.3 / Piece

CONN EDGECARD 60POS R/A .100 SLD
EBC30DCAH-S189 evaluate
US $3.97 - 3.97 / Piece

CONN EDGECARD 60POS R/A .100 SLD

Product Details

Quick Details

Series:	-	Manufacturer:	Sullins Connector Solutions
Card Type:	Non Specified - Dual Edge	Gender:	Female
Number of Positions/Bay/Row:	36	Continuous Collector Current at 25 C :	45 A
Number of Positions:	72	Card Thickness:	0.031" (0.79mm)
Number of Rows:	2	Pitch:	0.100" (2.54mm)
Features:	-	Mounting Type:	Panel Mount
Termination:	Solder Eyelet(s)	Contact Material:	Phosphor Bronze
Contact Finish:	Gold	Contact Finish Thickness:	10µin (0.25µm)
Contact Type:	Full Bellows	Color:	Blue
Packaging:	Tray

Description

Gender: Female
Number of Rows: 2
Pitch: 0.100" (2.54mm)
Features: -
Contact Material: Phosphor Bronze
Contact Finish: Gold
Card Type: Non Specified - Dual Edge
Number of Positions: 72
Packaging: Tray
Series: -
Mounting Type: Panel Mount
Termination: Solder Eyelet(s)
Manufacturer: Sullins Connector Solutions
Contact Finish Thickness: 10µin (0.25µm)
Contact Type: Full Bellows
Color: Blue
Number of Positions/Bay/Row: 36
Flange Feature: Top Mount Opening, Floating Bobbin, 0.116" (2.95mm) Dia
Card Thickness: 0.031" (0.79mm)

Parameters:

Technical/Catalog Information	EBC36DREF-S734
Vendor	Sullins Connector Solutions
Category	Connectors
Card Thickness	0.031" (0.79mm)
Card Type	Dual Edge
Contact Finish	Gold
Mounting Type	Panel Mount, Solder Eyelet
Features	Flange
Number of Positions	72
Number of Rows	2
Pitch	0.100" (2.54mm)
Packaging	Tray
Color	-
Contact Finish Thickness	10in (0.25m)
Gender	Female
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EBC36DREF S734 EBC36DREFS734
