EA218E

Storage Temperature................................................. -50°C to +125°C
Operating Temperature ...................................................0°C to +70°C
Supply Voltage VDD with Respect to VSS .......................+3.0 V to +3.6 V
Voltage on 5V Tolerant Input Pins........................ -0.5 V to (VDD + 1.8 V)
Voltage on Other Input Pins ..................................-0.5 V to (VDD + 10%)
Stresses above those listed may cause permanent device failure. Functionality at or above these limits is not implied. Exposure to Ab- solute Maximum Ratings for extended periods may affect device reliability.

The EA-218E provides eight 10Mbps Ethernet network access interface ports.

The EA-218E provides the Ethernet MAC protocols, handles the local buffer memory interface and management, arbitrates among multiple priority queues, and interfaces with the XpressFlow Engine and other Access Controllers through the XpressFlow message passing protocol.
