See larger image

SeekIC No. : 003429235 Detail

DSEP75-06AR: DIODE FRED 600V 75A ISOPLUS247

DSEP75-06AR Data Sheet

Get Latest Price

Part Number:: DSEP75-06AR
Mfg:
Supply Ability:: 5000

Price Break

Qty
1~5000

Unit Price
Negotiable

Processing time
15 Days

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/12/25

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

DSEP 30-06A evaluate
Features: • International standard package• Planar passivated chips• Very short ...
DSEP 30-06B evaluate
Features: • International standard package• Planar passivated chips• Very short ...
DSEP 30-06BR evaluate
Features: • International standard package• Planar passivated chips• Very short ...

Product Details

Quick Details

Series:	HiPerFRED™	Manufacturer:	IXYS
Diode Type:	Standard	Voltage - DC Reverse (Vr) (Max):	600V
Current - Average Rectified (Io):	75A	Current - Average Rectified (Io) (per Diode):	-
Gate-Source Breakdown Voltage :	30 V	Voltage - Forward (Vf) (Max) @ If:	2.02V @ 75A
Speed:	Fast Recovery = 200mA (Io)	Reverse Recovery Time (trr):	35ns
Current - Reverse Leakage @ Vr:	1mA @ 600V	Capacitance @ Vr, F:	-
Diode Configuration:	-	Mounting Type:	Through Hole, Radial
Package / Case:	ISOPLUS247?	Supplier Device Package:	ISOPLUS247?

Description

Diode Type: Standard
Current - Average Rectified (Io) (per Diode): -
Speed: Fast Recovery = 200mA (Io)
Diode Configuration: -
Capacitance @ Vr, F: -
Voltage - DC Reverse (Vr) (Max): 600V
Reverse Recovery Time (trr): 35ns
Packaging: Tube
Mounting Type: Through Hole, Radial
Current - Reverse Leakage @ Vr: 1mA @ 600V
Manufacturer: IXYS
Series: HiPerFRED™
Current - Average Rectified (Io): 75A
Package / Case: ISOPLUS247?
Supplier Device Package: ISOPLUS247?
Voltage - Forward (Vf) (Max) @ If: 2.02V @ 75A

Parameters:

Technical/Catalog Information	DSEP75-06AR
Vendor	IXYS
Category	Discrete Semiconductor Products
Diode Type	Standard
Voltage - DC Reverse (Vr) (Max)	600V
Current - Average Rectified (Io)	75A
Voltage - Forward (Vf) (Max) @ If	2.02V @ 75A
Reverse Recovery Time (trr)	35ns
Current - Reverse Leakage @ Vr	1mA @ 600V
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Mounting Type	Through Hole, Radial
Package / Case	ISOPLUS247?
Packaging	Tube
Capacitance @ Vr, F	-
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	DSEP75 06AR DSEP7506AR
