DS9637ACM

Logic Family :
Receiver Signal Type : Differential
Packaging : Tube
Maximum Operating Temperature : + 70 C
Minimum Operating Temperature : 0 C
Number of Receivers : 2
Operating Supply Voltage : 5 V
Interface Type : EIA-422, EIA-423, RS-422, RS-423
Package / Case : SOIC-8 Narrow


Pinout








Description

The DS9637ACM is one member of the DS9637A family which designed as the schottky dual differential line receiver that has been specifically designed to satisfy the requirements of EIA Standards RS-422 and RS-423.It is suitable for use as a line receiver in digital data systems, using either single ended or differential, unipolar or bipolar transmission and requires a single 5V power supply and has Schottky TTL compatible outputs.

Features of the DS9637ACM are:(1)dual channel;(2)single 5V supply;(3)satisfies EIA standards RS-422 and RS423;(4)built-in ±35 mV hysteresis;(5)high input common mode voltage range;(6)high input impedance;(7)TTL compatible outputs;(8)schottky technology;(9)extended temperature range.

The absolute maximum ratings of the DS9637ACM can be summarized as:(1)storage temperature range (ceramic D):-65°C to +175°C;(2)storage tempera-ture range (molded DIP):-65°C to +150°C;(3)maximum power dissipation at 25°C (cavity package):1300 mW;(4)input potential to ground:±15V;(5)differential input voltage:±15V;(6)output potential to ground:-0.5V to +5.5V;(7)output sink current:50 mA;(8)Vcc lead potential to ground:-0.5V to 7.0V.If you want to know more information such as the electrical characteristics about the DS9637ACM,please download the datasheet in www.seekic.com or www.chinaicmart.com.

The DS9637ACM is designed as one kind of schottky dual differential line receiver device that can be used as a line receiver in digital data systems, using either single ended or differential, unipolar or bipolar transmission.

Features of the DS9637ACM are:(1)Dual channel; (2)Single 5V supply; (3)Satisfies EIA standards RS-422 and RS423; (4)Built-in ±35 mV hysteresis; (5)High input common mode voltage range; (6)High input impedance; (7)TTL compatible outputs; (8)Schottky technology; (9)Extended temperature range.

The absolute maximum ratings of the DS9637ACM can be summarized as:(1)Storage Temperature Range Ceramic DIP: -65 to +175;(2)Storage Temperature Range Molded DIP: -65 to +150;(3)Operating Temperature Range: -55 to +125;(4)Lead Temperature Ceramic DIP (Soldering, 60 seconds): 300;(5)Lead Temperature Molded DIP (Soldering, 10 seconds): 265;(6)Input Voltage: 15 V;(7)Output Voltage: 15 V;(8)VCC Lead Potential to Ground: -0.5V to 7.0V;(9)Output Potential to Ground: -0.5V to +5.5V. If you want to know more information about it, please download the datasheet in www.seekic.com or www.chinaicmart.com .
