DS90LV011AQ

PinoutSpecificationsPHY TypeLine DriverFamilyLVDSChannels1 ChannelsMax Data Rate400 MbpsInput CompatibilityLVTTLOutput CompatibilityLVDSPower Consumption_17 mWSupplyVoltage3.3 VoltJTAG1149.1NoTemperature Min-40 deg CTemperature Max125 deg CAEC Q-100 Automotive Grade1Automotive Selection GuideYesFu...

product image

DS90LV011AQ Picture
See larger image
SeekIC No. : 004329386 Detail

DS90LV011AQ: PinoutSpecificationsPHY TypeLine DriverFamilyLVDSChannels1 ChannelsMax Data Rate400 MbpsInput CompatibilityLVTTLOutput CompatibilityLVDSPower Consumption_17 mWSupplyVoltage3.3 VoltJTAG1149.1NoTemper...

DS90LV011AQ Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
DS90LV011AQ
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/25

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Pinout




Specifications

PHY TypeLine Driver
FamilyLVDS
Channels1 Channels
Max Data Rate400 Mbps
Input CompatibilityLVTTL
Output CompatibilityLVDS
Power Consumption_17 mW
SupplyVoltage3.3 Volt
JTAG1149.1No
Temperature Min-40 deg C
Temperature Max125 deg C
AEC Q-100 Automotive Grade1
Automotive Selection GuideYes
FunctionDriver
View Using Catalog



Description

The DS90LV011AQ is an LVDS driver optimized for high data rate and low power applications. The DS90LV011AQ is a current mode driver allowing power dissipation to remain low even at high frequency. In addition, the short circuit fault current is also minimized. The device is designed to support data rates in excess of 400Mbps (200MHz) utilizing Low Voltage Differential Signaling (LVDS) technology.

The device is offered in a 5-lead small outline transistor package. The LVDS outputs have been arranged for easy PCB layout. The differential driver outputs provide low EMI with its typical low output swing of 350 mV. The DS90LV011AQ can be paired with its companion single line receiver, the DS90LT012AQ, or with any of National's LVDS receivers, to provide a high-speed LVDS interface.

Reliability Metrics

Part Number Process EFR Reject EFR Sample Size PPM LTA Rejects LTA Device Hours FITS MTTF (Hours)
DS90LV011AQMF CMOS7 0 16561 0 0 954000 4 270700104
DS90LV011AQMFE CMOS7 0 16561 0 0 954000 4 270700104
DS90LV011AQMFX CMOS7 0 16561 0 0 954000 4 270700104

Note: The Early Failure Rates (EFR) were calculated as point estimate PPM based on rejects and sample size for EFR. The Long Term Failure Rates were calculated at 60% confidence using the Arrhenius equation at 0.7eV activation energy and derating the assumed stress temperature of 150°C to an application temperature of 55°C.

For more information on Reliability Metrics, please click here.
