DS3695T

PinoutSpecificationsFunctionTransceiverChannels1 ChannelsMax Data Rate10 MbpsSupplyVoltage5 VoltProcessBipolarSpecial Features'176 pinoutTemperature Min-40 deg CTemperature Max85 deg CJTAG1149.1NoDrivers1Receivers1 View Using CatalogDescriptionThe DS3695, DS3696, and DS3697 are high speed differen...

product image

DS3695T Picture
See larger image
SeekIC No. : 004329051 Detail

DS3695T: PinoutSpecificationsFunctionTransceiverChannels1 ChannelsMax Data Rate10 MbpsSupplyVoltage5 VoltProcessBipolarSpecial Features'176 pinoutTemperature Min-40 deg CTemperature Max85 deg CJTAG1149.1NoDr...

DS3695T Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
DS3695T
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/1/2

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Pinout




Specifications

FunctionTransceiver
Channels1 Channels
Max Data Rate10 Mbps
SupplyVoltage5 Volt
ProcessBipolar
Special Features'176 pinout
Temperature Min-40 deg C
Temperature Max85 deg C
JTAG1149.1No
Drivers1
Receivers1
View Using Catalog



Description

The DS3695, DS3696, and DS3697 are high speed differential TRI-STATE® bus/line transceivers/repeaters designed to meet the requirements of EIA standard RS485 with extended common mode range (+12V to -7V), for multipoint data transmission.

The driver and receiver outputs feature TRI-STATE capability. The driver outputs remain in TRI-STATE over the entire common mode range of +12V to -7V. Bus faults that cause excessive power dissipation within the device trigger a thermal shutdown circuit, which forces the driver outputs into the high impedance state. The DS3696 provides an output pin TS (thermal shutdown) which reports the occurrence of the thermal shutdown of the device. This is an "open collector" pin with an internal 10 k pull-up resistor. This allows the line fault outputs of several devices to be wire OR-ed.

Both AC and DC specifications of DS3695, DS3696, and DS3697 are guaranteed over the 0°C to 70°C temperature and 4.75V to 5.25V supply voltage range.
