DP52-0005

Features:

*  Small Size and Low Profile
*  Industry Standard SOT-26 SMT Plastic Package
*  Superior Repeatability
*  Passbands 824 - 960 MHz and 1850 - 1990 MHz
*  Passbands 880 - 960 MHz and 1700 - 1900 MHz
*  Typical Passband Insertion Loss: 0.5 dB
*  2 Watt Power Handling
*  Low Cost


Specifications

Parameter                                          Absolute Maximum
Input Power                                                 2 W CW
Operating  Temperature                       -40 to +85
Storage Temperature                           -65 to +150


Description

M/A-COM's DP52-0005 is an IC-based monolithic Diplexer in a low cost SOT-26 plastic package. This Diplexer is ideally suited for applications where small size, low insertion loss, superior  repeatability and low cost are required.  Typical applications include AMPS/PCS and GSM/DCS dual mode  portable devices.

The DP52-0005 is fabricated using a passive-integrated circuit process.  The process features full-chip passivation for increased performance and reliability.
