Product Details

Description

Features:

Epitaxial Planar Die Construction
Intrinsically Matched NPN Pair (Note 1)
Small Surface Mount Package
2% Matched Tolerance, h_FE, V _CE(SAT), V _BE(SAT)
1% Matched Tolerance, Available (Note 2)

Pinout

Specifications

Part Number	DMMT3904W
Product Type	NPN + NPN
V _CEO(V)	40
@ I_C (A)	0.01
P_D (W)	0.2
h_FE Min	100
h_FE Max	300
V_{CE (SAT)}(mV)	200
@ I_B (mA)	1
f_T(MHz)	300

Characteristic	Symbol	DMDT9922	Unit
Collector-Base Voltage	V_CBO	60	V
Collector-Emitter Voltage	V_CBO	40	V
Emitter-Base Voltage	V_EBO	6.0	V
Collector-Collector Voltage	V_CCO	200	mA
Power Dissipation (Note 3)	P_d	200	mW
Thermal Resistance, Junction to Ambient (Note3)	R_JA	625	/W
Operating and Storage and Temperature Range	T_j,T_STG	-55 to +150
