DM1810-916MR

Memory Size: -
Operating Temperature: -40°C ~ 85°C
Sensitivity: -
Package / Case: Module
Data Interface: Pads for Pins
Applications: Wireless Mesh Networks
Packaging: -
Manufacturer: RFM
Frequency: 916.5MHz
Power - Output: 10mW
Modulation or Protocol: OOK
Series: DM1810
Data Rate - Maximum: 4.8kbps
Current - Receiving: 5.5mA
Current - Transmitting: 15.75mA
Antenna Connector: On-Board, Spring
Voltage - Supply: 2.6 V ~ 10 V


Specifications

Characteristic Symbol Minimum Typical Maximum Units Operating Frequency fO 916.30 916.70 MHz Modulation Type OOK on BPSK Spreading Code RF Encoded Data Transmission Rate 4.8 kb/s Average Receive Input Current, No External Power Supply Load IR 5.5 mA Receiver Input Signal for 10-3 BER, 25 C -100 dBm Average Transmit Input Current, No External Power Supply Load ITA 15.75 mA Peak Transmit Input Current, No External Power Supply Load ITP 32 mA Peak Transmitter Output Power PO 10 mW Bind Input Logic High 2.4 V Bind Input Logic Low 0.45 V Average Sleep Input Current, No External Power Supply Load ISA 60 ?A Power Supply Input Voltage Range, -40 to +85 oC VIN 3.1 10 V Power Supply Input Voltage Range, 0 to +85 oC VIN 2.6 10 V Regulated Power Supply Output Voltage, VIN 3.1 to 10 V VOUT 3.0 Vdc Regulated Power Supply Voltage Ripple 10 mVP-P Relative Humidity Range, Non-Condensing RH 10 90 %


Description

DM1810-916MR:

Network Router Compatible with RFM miniMESHTM Network Protocol 3 V, Very Low Current Operation Ready-to-Use OEM Module
