Product Details

Description

Features:

* Very Fast Reverse Recovery
* Soft Recovery Characteristics
* Low Forward Voltage Drop
* UL registered E76102

Application

* Welding and Plasma Cutting Machines
* DC chopper
* Rectifier in Switch Mode Power Supplies (SMPS)
* Uninterruptible Power Supplies (UPS)
* Free Wheeling Diode in converters and motor control circuits

Specifications

Symbol	Item		Ratings		Unit
Symbol	Item		DKA300AA50	DKA300AA60	Unit
V_RRM	Repetitive Peak Reverse Voltage		500	600	V
V_R(DC)	Reverse D.C. Voltage		400	480	V
Symbol	Item		Conditions	Ratings	Unit
I_F(AV)	Average Forward Current		D.C., T C = 72°C	150	A
I_FSM	Surge Forward Current		½ cycle, 60Hz, Peak value, non-repetitive	2500	A
I²t	I²t (for fusing)		Value for one cycle surge current	26000	A²s
T_j	Junction Temperature			-40 to +150	°C
T_stg	Storage Temperature			-40 to +125	°C
V _ISO	Isolation Voltage (R.M.S.) A.C. 1 minute			2500	V
	Mounting Torque	Mounting M6	Recommended 2.5-3.9 (25-40)	4.7(48)	N.m (kgfžcm)
	Mounting Torque	Terminal M5	Recommended 1.5-2.5 (15-25)	2.7(28)	N.m (kgfžcm)
	Mass		Typical Value	170	g

Description

Soft Recovery Diode Module DKA300AA is designed for applications requiring fast switching and soft recovery wave shape to reduce or eliminate the need for snubber components in the circuit. The modules DKA300AA are isolated for easy mounting with other components or a common heatsink.
