DIM375WKS06-S000

Features: · Low Forward Voltage Drop· Isolated Copper BaseplateApplication· Choppers· Motor ControllersSpecificationsStresses above those listed under 'Absolute Maximum Ratings' may cause permanent damage to the device. In extreme conditions, as with all semiconductors, this may include potentiall...

product image

DIM375WKS06-S000 Picture
See larger image
SeekIC No. : 004326493 Detail

DIM375WKS06-S000: Features: · Low Forward Voltage Drop· Isolated Copper BaseplateApplication· Choppers· Motor ControllersSpecificationsStresses above those listed under 'Absolute Maximum Ratings' may cause permanent ...

DIM375WKS06-S000 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
DIM375WKS06-S000
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/10/20

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

· Low Forward Voltage Drop
· Isolated Copper Baseplate


Application

· Choppers
· Motor Controllers


Specifications

Stresses above those listed under 'Absolute Maximum Ratings' may cause permanent damage to the device. In extreme conditions, as with all semiconductors, this may include potentially hazardous rupture of the package. Appropriate safety precautions should always be followed. Exposure to Absolute Maximum Ratings may affect device reliability.

Tcase = 25°C unless stated otherwise
Symbol Parameter Test Conditions
Max.
Units
VCES Collector-emitter voltage VGE = 0V

600
V
VGES Gate-emitter voltage
±20
V
IC Continuous collector current Tcase =65˚C
375
A
IC(PK) Peak collector current 1ms, Tcase = 95˚C
750
A
Pmax Max. transistor power dissipation Tcase = 25˚C, Tj = 150˚C
1736
W
I2t Diode I2t value VR = 0, tp = 10ms, Tvj = 125˚C
TBD
kA2S
Visol Isolation voltage - per module Commoned terminals to base plate. AC RMS,1 min, 50Hz
2.5
kV



Description

The Powerline range of modules includes half bridge, chopper, bi-directional, dual and single switch configurations covering voltages from 600V to 3300V and currents up to 3600A.

The DIM375WKS06-S000 is a 600V n channel enhancement mode, insulated gate bipolar transistor (IGBT) chopper module configured with the upper arm of the bridge controlled. The module is suitable for a variety of medium voltage applications in motor drives and power conversion.

The IGBT has a wide reverse bias safe operating area (RBSOA) for ultimate reliability in demanding applications. These modules(DIM375WKS06-S000) incorporate electrically isolated base plates and low inductance construction enabling circuit designers to optimise circuit layouts and utilise earthed heat sinks for safety.

Typical applications include dc motor drives, ac pwm drivesand ups systems..
