DA100

Features:

·Compatible with Leading Chip Sets
·2kVrms Isolation
·Standard Pinout
·Surface Mount Option
·CECC00802 IR Reflow Profile
·UL 94V-0 Package Materials
·Low Profile
·Suitable for Both 75 & 110W Circuits


Specifications

Operating free air temperature range               0 to 70
Storage temperature range                        40 to 125

Description

The Digital Audio Range of transformers DA100 is designed to improve the balance of transmitter and receiver circuitry in hi-fi equipment, video games and other applications requiring high-performance digital audio transmission. Compliant with AES/EBU recommendations for the digital audio interface offering optimised shunt capacitance between primary and secondary windings. Capable of operating over the audio data rate frequency range, providing isolation from 60Hz noise.
