Product Details

Description



Features:

• SIMPLIFIED AMPLIFIER DESIGN
• SUITABLE FOR BROAD BAND APPLICATIONS
• VERY LOW Crss
• SIMPLE BIAS CIRCUITS
• LOW NOISE
• HIGH GAIN 10 dB MINIMUM



Application

• HF/VHF/UHF COMMUNICATIONS from 1 MHz to 1 GHz


Pinout

  Connection Diagram


Specifications

PD Power Dissipation 30W
BVDSS Drain Source Breakdown Voltage 40V
BVGSS Gate Source Breakdown Voltage ±20V
ID(sat) Drain Current 10A
Tstg Storage Temperature 65 to 150°C
Tj Maximum Operating Junction Temperature 200°C
