Features: ·Powerful Harvard Architecture Processor·M8C Processor Speeds to 24 MHz·Two 8x8 Multiply, 32-Bit Accumulate·Low Power at High Speed·3.0V to 5.25V Operating Voltage·Operating Voltages Down to 1.0V Using On-Chip Switch Mode Pump (SMP)·Industrial Temperature Range: -40°C to +85°C·Advanced P...
CY8C29866: Features: ·Powerful Harvard Architecture Processor·M8C Processor Speeds to 24 MHz·Two 8x8 Multiply, 32-Bit Accumulate·Low Power at High Speed·3.0V to 5.25V Operating Voltage·Operating Voltages Down ...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
US $1.12 - 1.24 / Piece
Programmable Systems-on-a-Chip (PSoC) PROGRAMMABLE SYSTEM Ochip
US $1.12 - 1.2 / Piece
Programmable Systems-on-a-Chip (PSoC) CAPSENSE CONTROLLER
US $1.27 - 1.41 / Piece
Programmable Systems-on-a-Chip (PSoC) CAPSENSE CONTROLLER
Symbol | Absolute Maximum Ratings | Min | Typical | Max | Unit | Notes |
TSTG | Storage Temperature | -55 | - | +100 | Higher storage temperatures will reduce data retention time. | |
TA | Ambient Temperature with Power Applied | -40 | - | +85 | ||
Vdd | Supply Voltage on Vcc Relative to Vss | -0.5 | - | +6.0 | V | |
VIO | DC Input Voltage | Vss-0.5 | - | Vcc+0.5 | V | |
DC Voltage Applied to Tri-state | Vss-0.5 | - | Vcc+0.5 | V | ||
IMIO | Maximum Current into any Port Pin | -25 | - | +50 | mA | |
IMAIO | Maximum Current into any Port Pin Configured as Analog Driver |
-50 | - | +50 | mA | |
IMAIO | Electro Static Discharge Voltage | 2000 | - | - | Human Body Model ESD | |
Latch-up Current | - | - | 200 |
