Product Details

Description



Features:

• 4:1 input voltage range
• Operating ambient temperature of -40 to +70 in still air
• High demonstrated reliability with conservative component deratings
• Complies with ETS 300 019-1-3/2-3
• Complies with ETS 300 132-2 input voltage and current requirements
• Fully compliant with ETS 300 386-1
• Pin compatible with NFC10 and BXA10 series
• Basic insulation system (input to output)
• 2 year warranty




Specifications

  • Total Max Power: 10 W
  • Total Max Current: 2.4 A
  • Input Voltage: 18 V to 75 V
  • Output Voltage: -15 V to 15 V
  • Outputs: Single, Dual
  • Size (L x W x H): 2.000" x 1.000" x 0.394"
  • Warranty: 2 years
  • Operating Temperature: -40 to 70 oC





    • Description

    The CXA10 series comprising of five different models delivers single and dual output voltages covering 3.3 V, 5 V, 12 V, ±5 V, ±12 V and ±15 V. The series has a wide 4:1 input voltage range of 18Vdc to 75 Vdc. The CXA10 has been designed as a competitive open-frame alternative for the communications market. The product is supplied in the industry standard footprint of 2.0 x 1.0 x 0.394 inches. Other product features include overvoltage protection, short-circuit protection and remote ON/OFF.

    All components CXA10 are placed in a fully automated environment.Planar magnetics are used in the design to improve the reliability and reduce the profile of the dc-dc converter. The series has full international safety approvals reducing system compliance costs, and CXA10 has a basic insulation system from input to output making it suitable for a wide variety of applications.
