SeekIC No. : 003415010 Detail

CTED-A5B3-156.25TS: OSC TCXO 156.250 MHZ 3.3V LVPECL

CTED-A5B3-156.25TS Data Sheet

Get Latest Price

Part Number:: CTED-A5B3-156.25TS
Mfg:
Supply Ability:: 5000

Price Break

Qty
1~5000

Unit Price
Negotiable

Processing time
15 Days

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/12/30

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

CTED-A5B3-155.52TS evaluate
OSC TCXO 155.520 MHZ 3.3V LVPECL
CTED-A5B3-212.5TS evaluate
OSC TCXO 212.500 MHZ 3.3V LVPECL
CTED-A5B3-311.04TS evaluate
OSC TCXO 311.040 MHZ 3.3V LVPECL

Product Details

Quick Details

Series:	CTED	Manufacturer:	Cardinal Components Inc.
Type:	TCXO	Frequency:	156.25MHz
Function:	Tri-State (Output Enable)	Output:	LVPECL
Power Dissipation :	280 mW	Voltage - Supply:	3.3V
Frequency Stability:	±2.5ppm	Operating Temperature:	-20°C ~ 70°C
Current - Supply (Max):	100mA	Ratings:	-
Mounting Type:	Surface Mount	Size / Dimension:	0.551" L x 0.354" W (14.00mm x 9.00mm)
Height:	0.138" (3.50mm)	Package / Case:	6-SMD, No Lead (DFN, LCC)

Description

Function: Tri-State (Output Enable)
Voltage - Supply: 3.3V
Ratings: -
Mounting Type: Surface Mount
Operating Temperature: -20°C ~ 70°C
Package / Case: 6-SMD, No Lead (DFN, LCC)
Type: TCXO
Frequency Stability: ±2.5ppm
Current - Supply (Max): 100mA
Frequency: 156.25MHz
Packaging: Tube
Output: LVPECL
Manufacturer: Cardinal Components Inc.
Size / Dimension: 0.551" L x 0.354" W (14.00mm x 9.00mm)
Height: 0.138" (3.50mm)
Series: CTED

Parameters:

Technical/Catalog Information	CTED-A5B3-156.25TS
Vendor	Cardinal Components Inc.
Category	Crystals and Oscillators
Frequency	156.25MHz
Package / Case	SMD 14mm x 9mm
Packaging	Tube
Supply Voltage	3.3V
Type	TCXO
Operating Temperature	-20°C ~ 70°C
Frequency Stability	±2.5ppm
Supply Current	100mA
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	CTED A5B3 156 25TS CTEDA5B315625TS 370 1036 ND 3701036ND 370-1036
