CT1698

Features:

• Optional transformer isolation
• Internally set threshold
• Matched to 50 ohm system impedance power on and off
• Operates with ±5 volt supplies
• Power management
• External output level adjustment
• Accepts synchronous input data
• Unique Manchester decoder requires no clock
• Generates one clock per received bit
• May be used for serial decoding of indefinite word lengths
• Interfaces directly to the CT2500 protocol device
• Other Wire and Fiber Optic types available


Specifications

V_CC (Pins 23, 24).....................+7 Volts Max
V_EE (Pins 7, 17) ........................-7 Volts Max
Logic Input Voltage Applied:
Logic Low .......................-1.2V @ 10mA Max
Logic High ....................................+5.5 Volts


Description

CT1698 is a single hybrid microcircuit which incorporates a serial encoder, transceiver, and Manchester decoder in one package. The encoder accepts serial NRZ data in conjunction with two synchronous clocks. The CT1698 receiver section accepts bipolar Manchester encoded signals and passes level detected signals to the serial decoder. The CT1698 has a power management function and a variable drive level option. The transmitter standby mode is available to reduce the overall power consumption of the CT1698. The variable drive level output is externally programmable for testing purposes. Aeroflex Circuit Technology is a 80,000 square foot MIL-PRF-38534 certified facility in Plainview, N.Y.
