CSS-73B16K

Driver Circuitry: Transducer, Externally Driven
Input Type: zero-peak Signal
Operating Mode: Continuous
Washable: No
Packaging: Cut Tape (CT)Alternate Packaging
Manufacturer: CUI Inc
Technology: Magnetic
Mounting Type: Surface Mount
Termination: Solder Pads
Frequency: 2.73kHz
Voltage - Rated: 3.6Vo-p
Voltage Range: 2.5 ~ 4.5V
Series: CSS
Sound Pressure Level: 87dB @ 3.6V, 10cm
Current - Supply: 100mA
Size / Dimension: Square - 8.50mm L x 8.50mm W x 4.30mm H


Specifications

recommended circuits: click here

rated voltage: 3.6Vo-p

operating voltage: 2.5-4.5 Vo-p

mean current: 100mA

coil resistance: 16Ω ±2.4

coil impedance: 29Ω

sound pressure level: 87dB

rated frequency: 2.73kHz

operating temperature: -30 to +70°C

storage temperature: -40 to +85°C

dimensions (LxWxH): 8.5 mm x 8.5 mm x 4.0 mm

weight: 0.6 grams

640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram">

Parameters:

Technical/Catalog Information	CSS-73B16K
Vendor	CUI Inc (VA)
Category	Audio Products
Type	Magnetic Transducer, External Drive
Sound Pressure Level	87dB
Mounting Type	Surface Mount
Capacitance @ Frequency	-
Frequency	2.73kHz
Packaging	Cut Tape (CT)
Operating Mode	Continuous
Voltage Range	2.5~4.5Vo-p
Voltage - Rated	3.6Vo-p
Current Rating	100mA
Size / Dimension	Square - 8.5mm L x 8.5mm W x 4mm H
Termination	Solder Pads
Capacitance	*
Adjustment Type	*
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	CSS 73B16K CSS73B16K 102 1197 1 ND 10211971ND 102-1197-1
