CPE-750

Technology: Piezo
Operating Mode: Continuous
Washable: No
Packaging: Bulk
Manufacturer: CUI Inc
Series: CPE
Driver Circuitry: Indicator, Internally Driven
Input Type: DC
Voltage - Rated: 12VDC
Current - Supply: 8mA
Frequency: 3.6kHz
Voltage Range: 4 ~ 28V
Sound Pressure Level: 80dB @ 12V, 30cm
Mounting Type: Panel Mount
Termination: Quick Connect Tab - 0.189" (4.80mm)
Size / Dimension: Circular - 37.80mm Dia x 24.00mm H


Specifications

operating voltage: 4 ~ 28 V dc

operating frequency: 3.6 ± 0.5 kHz

current consumption: 8 mA

sound pressure level: 80 db

rated voltage: 12 V dc

tone: continuous

operating temperature: -30 ~ +85° C

storage temperature: -40 ~ +95° C

dimensions: ?37.8 x 23.5 mm

weight: 18.5 g

material: ABS UL-94 1/16" HB (gray)

termination: pin type

640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram">

Parameters:

Technical/Catalog Information	CPE-750
Vendor	CUI Inc
Category	Audio Products
Type	Piezo Indicator, Internal Drive
Sound Pressure Level	80dB
Mounting Type	Panel Mount
Capacitance @ Frequency	-
Frequency	3.6kHz
Packaging	Bulk
Operating Mode	Continuous
Voltage Range	4~28VDC
Voltage - Rated	12VDC
Current Rating	8mA
Size / Dimension	Circular - 37.8mm Dia x 23.5mm H
Termination	Quick Connect Tab - 0.189" (4.8mm)
Capacitance	*
Adjustment Type	*
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	CPE 750 CPE750 102 1654 ND 1021654ND 102-1654
