CNX39U

Maximum Collector Emitter Saturation Voltage : 0.4 V
Maximum Forward Diode Voltage : 1.5 V
Maximum Operating Temperature : + 100 C
Minimum Operating Temperature : - 40 C
Packaging : Bulk
Input Type : DC
Maximum Power Dissipation : 200 mW
Maximum Collector Emitter Voltage : 30 V
Isolation Voltage : 5300 Vrms
Package / Case : PDIP-6
Maximum Collector Current : 100 mA
Current Transfer Ratio : 100 %


Features:

• High output/input DC current transfer ratio
• Low saturation voltage
• UL recognized (File # E90700)
• VDE recognized (File # 94766) -Ordering option '300' (e.g. CNX35U.300)


Application

• Power supply regulators
• Digital logic inputs
• Microprocessor inputs
• Appliance sensor systems
• Industrial controls


Description

The CNX35U, CNX36U CNX38U and CNX39U are optically coupled isolators consisting of an infrared emitting GaAs diode and a silicon NPN phototransistor with accessible base. These devices are housed in 6-pin dual-inline packages (DIP).
