CMD91-21VGC/TR9

Standard LED - SMD GRN 2.1V 20MA

product image

CMD91-21VGC/TR9 Picture
See larger image
SeekIC No. : 0048991 Detail

CMD91-21VGC/TR9: Standard LED - SMD GRN 2.1V 20MA

CMD91-21VGC/TR9 Data Sheet

floor Price/Ceiling Price

US $ .12~.17 / Piece | Get Latest Price
Part Number:
CMD91-21VGC/TR9
Mfg:
Chicago Miniature
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~100
  • 100~500
  • 500~1000
  • Unit Price
  • $.17
  • $.15
  • $.13
  • $.12
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/23

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

LED Size : 2.5 mm x 2 mm Illumination Color : Green
Wavelength/Color Temperature : 565 nm Lens Color/Style : Clear
Forward Current : 20 mA Forward Voltage : 2.1 V
Luminous Intensity : 50 mcd Viewing Angle : 25 deg
Packaging : Reel

Description

Illumination Color : Green
Forward Current : 20 mA
Packaging : Reel
Forward Voltage : 2.1 V
Lens Color/Style : Clear
Luminous Intensity : 50 mcd
LED Size : 2.5 mm x 2 mm
Wavelength/Color Temperature : 565 nm
Viewing Angle : 25 deg


Pinout




Specifications

Part Number: CMD91-21VGC/TR9
Serial Number: CMD91
LED Type: SMT
Industry Size: Subminiature
Metric Size: 1.9 mm
Output Color: GREEN
Epoxy: WATER CLEAR
Peak Wave length (mA): 565
Minimum MCD: 30
Typical MCD: 50
Forward Volt (Typical): 2.1
Forward Volt (Max): 2.8
Rate Current (mA): 20
Viewing Angle (°): 25
Operating Temperature:
Storage Temperature:
Power Dissipation: 105
Cont Forward Current Max: 25
RoHS Status: Yes


Parameters:

Technical/Catalog InformationCMD91-21VGC/TR9
VendorCML Innovative Technologies Inc
CategoryOptoelectronics
ColorGreen
Lens Style/SizeRound, 1.9mm
Millicandela Rating50mcd
Voltage - Forward (Vf) Typ2.1V
Wavelength - Dominant565nm
Wavelength - Peak565nm
Current - Test20mA
Viewing Angle25°
Lens TypeClear
Luminous Flux7 mlm
Package / Case2.5mm x 2mm x 2.8mm
Mounting TypeSurface Mount, Bottom Entry
PackagingTape & Reel (TR)
Other Names CMD91 21VGC TR9
CMD9121VGCTR9
L63005TR ND
L63005TRND
L63005TR
