Features: Regulated output options: 1.5, 1.8, 2.5 and 3.3 volts1.0A output current Operates from 3.3V supply (5.0V for CM3002-33)Very low dropout voltage on CM3002-33 products (500mV@1A)Enable Output Control for power-up sequencingLow quiescent operating current (< 600µA typical)Current l...
CM3002: Features: Regulated output options: 1.5, 1.8, 2.5 and 3.3 volts1.0A output current Operates from 3.3V supply (5.0V for CM3002-33)Very low dropout voltage on CM3002-33 products (500mV@1A)Enable Outpu...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Features: · Low Drive Power· Low VCE(sat)· Discrete Super-Fast Recovery Free-Wheel Diode· High Fre...
The CM3002 family of regulators are very low dropout regulators that deliver up to 1.0A of load current at a fixed voltage output. Input and output voltage options for the CM3002 family devices are presented in Table 1.
Operating from a single input supply, CM3002 are ideally suited for powering low voltage "core" proces-sors, especially where a 3.3V source is already avail-able.
These regulators feature a dedicated control input (EN,Active High) for power-up sequencing flexibility. When this input is taken low, the regulator output is disabled. In this state, the supply current will drop to a low level to ensure all the internal control circuitry still remains active. This provides excellent start-up response when-ever the device comes out of shutdown.
The CM3002 family of regulators is fully protected, offering both overload current limiting and high temper-ature thermal shutdown. Housed in space saving ther-mally-enhanced SOIC-8 and MSOP-8 (CM3002-33MA/MF) packages, these devices ensure maximum junc-tion-to-ambient power dissipation.
The CM3002 is available with optional lead-free finish-ing.
