CHV2707-QJ

The CHV2707 internally pre-matched power HBT device provides 14 dB of gain, 2.3% EVM at 30dBm output power for 802.16 OFDM signal with a peak to average power ratio of 9 dB. CHV2710 operates off a single supply voltage up to 12V and includes internal bias circuitry to enable exact setting of the quiescent current using an external Vcontrol. This Vcontrol is non-unique voltage setting and the same value can be used for each part depending on the required Icq. CHV2710 is ideal for high linearity, high data rate applications such as WiMAX. Internal pre-matching facilitates a simplified external matching approach and the highest in-band gain potential of the device. CHV2710 operates with unique matching at each of the popular WiMAX bands with the inherent repeatability of an InGaP HBT process.
