CEM-1601

Driver Circuitry: Transducer, Externally Driven
Input Type: zero-peak Signal
Operating Mode: Continuous
Mounting Type: Through Hole
Termination: PC Pins
Packaging: Bulk
Series: CEM
Manufacturer: CUI Inc
Technology: Magnetic
Voltage - Rated: 1.5Vo-p
Frequency: 2.048kHz
Sound Pressure Level: 80dB @ 1.5V, 10cm
Current - Supply: 20mA
Washable: Yes
Voltage Range: 1 ~ 3V
Size / Dimension: Circular - 16.00mm Dia x 14.50mm H


Specifications

recommended circuits: click here

rated voltage: 1.5Vo-p

operating voltage: 1-3Vo-p

mean current: 20mA

coil resistance: 30Ω ±4.5

coil impedance: 105Ω

sound pressure level: 80dB

rated frequency: 2048 Hz ±200

operating temperature: -20 to +60°C

storage temperature: -30 to +70°C

diameter: 16.0 mm

depth: 14.0 mm

weight: 4.6 grams

termination: PC pins

640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram">

Parameters:

Technical/Catalog Information	CEM-1601
Vendor	CUI Inc
Category	Zspecial
Sensitivity	+25mV/%RH
Voltage - Rated	*
Current	0.066mA
Type	*
Size / Dimension	*
Frequency	*
S/N Ratio	*
Filter Type	*
Impedance	*
Termination	*
Direction	*
Port Location	*
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	CEM 1601 CEM1601 102 1112 ND 1021112ND 102-1112
