CEM-1212S

Driver Circuitry: Transducer, Externally Driven
Input Type: zero-peak Signal
Operating Mode: Continuous
Mounting Type: Through Hole
Termination: PC Pins
Packaging: Bulk
Series: CEM
Manufacturer: CUI Inc
Technology: Magnetic
Frequency: 2.4kHz
Washable: Yes
Current - Supply: 40mA
Size / Dimension: Circular - 12.00mm Dia x 10.00mm H
Voltage - Rated: 12Vo-p
Voltage Range: 6 ~ 16V
Sound Pressure Level: 85dB @ 12V, 10cm


Specifications

recommended circuits: click here

rated voltage: 12Vo-p

operating voltage: 6-16Vo-p

mean current: 40mA

coil resistance: 140Ω ±21

coil impedance: 240Ω

sound pressure level: 85dB

rated frequency: 2400 Hz ±200

operating temperature: -20 to +60°C

storage temperature: -30 to +70°C

diameter: 12.0 mm

depth: 9.5 mm

weight: 1.6 grams

termination: PC pins

640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram">

Parameters:

Technical/Catalog Information	CEM-1212S
Vendor	CUI Inc
Category	Audio Products
Type	Magnetic Transducer, External Drive
Sound Pressure Level	85dB
Mounting Type	Through Hole
Capacitance @ Frequency	-
Frequency	2.4kHz
Packaging	Bulk
Operating Mode	Continuous
Voltage Range	6 ~ 16Vo-p
Voltage - Rated	12Vo-p
Current Rating	40mA
Size / Dimension	Circular - 12mm Dia x 9.5mm H
Termination	Solder Pins/Posts
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	CEM 1212S CEM1212S 102 1156 ND 1021156ND 102-1156
