C60

The C60 is a kind of solid state relay. It is an advanced design capable of switching very heavy loads in a physically small 6 pin mini DIP package. The relay has a power FET output that ensures low ON resistance, no offset votlage and low leakage current. It can be used to switch AC, Bi-directional or DC loads. Optical isolation ensures complete protection of signal lines, power and ground bus and control circuits from switching noise and EMI.

There are some C60 features as follows: (1)three terminal output: output FETs can be paralleled externally to change current load rating; (2)floating output: allows for high and low side switching; (3)C60 switches high voltages and currents: voltages to 400 Vdc, current to 2.5 Adc. Bi-directional, DC, or AC; (4)high noise immunity: control circuit can not be triggered by output switching noise; (5)6 pin mini-DIP package: standard or surface mount available.

The following is about C60 electrical specifications (25 unlesss otherwise specified): (1)control voltage range: 1.1 Vdc min and 1.5 Vdc; (2)input current: 50 mA max; (3)input current (guaranteed on): 5.0 mA min; (4)turn-off voltage (guaranteed off): 0.8 Vdc; (5)reverse voltage protection: -6 Vdc.
