C566C-BFN-VT0W0451-0MT

Specifications

Opto-Electrical Characteristics (Ta=25°C) Characteristics Symbol Test Condition Min Typ Max Unit Forward Voltage V_F IF=20mA - 3.4
4.0
V Reverse Current I_R VR=5V - - 100
μA Luminous Intensity I_V IF=20mA 770
1,500
- mcd Viewing Angle 2q1/2 - - 70° x 35° - deg Peak Wavelength lpeak IF=20mA - 465
- nm Dominant Wavelength lD IF=20mA - 470
- nm Spectral Line Half-Width Dl1/2 IF=20mA - 26
- nm
