BXA10-12S15J

The dc-dc converter BXA10-12S15J comprising 7 different models, is designed for a wide range of applications including communications, industrial systems and mobile battery powered systems.

The features of BXA10-12S15J can be summarized as:(1)1 x 2 x 0.395 inch package with stand-offs; (2)13.3 Watts/in3 power density; (3)CISPR22 and EN55022 conducted emission level A; (4)UL, CSA and VDE approvals(48V input only); (5)Continuous short circuit protection; (6)Optional remote ON/OFF; (7)Available RoHS compliant; (8)2 year warranty.

The ordering informations of the BXA10-12S15J are:(1)input voltage:9V to 18V;(2)output voltage:15V;(3)output current:0.67A;(4)input current:1.05A;(5)typical efficiency:85%;(6)OVP:18V;(7)line regulation:±0.2%;(8)load regualtion:±0.5%.

If you want to know more information such as the electrical characteristics about the BXA10-12S15J, please download the datasheet in www.seekic.com or www.chinaicmart.com .
