Transistors Bipolar (BJT) RAIL BIPOLAR
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
US $.07 - .07 / Piece
Transistors Bipolar (BJT) Trans GP BJT NPN 400V 1A 3-Pin SPT
US $.14 - .25 / Piece
Transistors Bipolar (BJT) Trans GP BJT NPN 400V 1A 3-Pin SPT
Transistor Polarity : | NPN | Collector- Emitter Voltage VCEO Max : | 400 V |
Maximum DC Collector Current : | 4 A | DC Collector/Base Gain hfe Min : | 10 |
Configuration : | Single | Maximum Operating Temperature : | + 150 C |
Mounting Style : | SMD/SMT | Package / Case : | SOT-78 |
Packaging : | Rail |
SYMBOL | PARAMETER | CONDTIONS |
MIN. |
MAX. |
UNIT |
VCESM VCEO VCBO IC ICM IB IBM Ptot Tstg Tj |
Collector to emitter voltage Collector to emitter voltage (open base) Collector to base voltage (open emitter) Collector current (DC) Collector current peak value Base current (DC) Base current peak value Total power dissipation Storage temperature Junction temperature |
VBE=0V Ths25 |
- - - - - - - - -65 - |
700 400 700 4 8 2 4 80 150 150 |
V V V A A A A W |
