BT149G,412

Rated Repetitive Off-State Voltage VDRM : 600 V
On-State RMS Current (It RMS) : 0.8 A
Holding Current (Ih Max) : 5 mA
Mounting Style : Through Hole
Package / Case : TO-92
Packaging : Bulk
Maximum Gate Peak Inverse Voltage : 5 V
Gate Trigger Current (Igt) : 50 uA
Off-State Leakage Current @ VDRM IDRM : 0.05 mA
Breakover Current IBO Max : 9 A
Forward Voltage Drop : 1.25 V
Gate Trigger Voltage (Vgt) : 0.3 V


Parameters:

Technical/Catalog Information	BT149G,412
Vendor	NXP Semiconductors
Category	Discrete Semiconductor Products
SCR Type	Sensitive Gate
Voltage - Off State	600V
Current - On State (It (RMS) (Max)	800mA
Current - On State (It (AV)) (Max)	500mA
Current - Gate Trigger (Igt) (Max)	200A
Current - Hold (Ih) (Max)	5mA
Current - Non Rep. Surge 50, 60Hz (Itsm)	8A, 9A
Voltage - Gate Trigger (Vgt) (Max)	800mV
Mounting Type	Through Hole
Package / Case	TO-92-3
Packaging	Bulk
Drawing Number	568; SOT54; ; 5
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	BT149G,412 BT149G,412 568 3672 ND 5683672ND 568-3672
