Product Details

Description

Features:

· Direct interface to C-MOS, TTL, etc.
· High-speed switching
· No secondary breakdown.

Specifications

SYMBOL	PARAMETER	CONDITIONS	MIN.	MAX.	UNIT
V_DS	drain-source voltage			50	V
±V_GSO	gate-source voltage	open drain		20	V
I_D	DC drain current			175	mA
I_DM	peak drain current			300	A
P_tot	total power dissipation	up to T_amb = 25 °C; note 1		830	W
T_stg	storage temperature		-65	150	°C
T_j	operating junction temperature			150	°C

Note:1. Device mounted on a printed circuit board, maximum lead length 4 mm.

Description

N-channel enhancement mode vertical D-MOS transistor BSN10A in a TO-92 envelope, intended for use in general purpose fast switching applications.
