BR8005

Features: ·Surge overload rating -200 amperes peak·Low forward voltage drop·Small size; simple installation·Sliver plated copper leads·Mounting position: AnySpecifications RATING SYMBOL BR8005 BR801 BR802 BR804 BR806 BR808 BR810 UNITS Maximum Recurrent Peak Reverse Voltage VRRM ...

product image

BR8005 Picture
See larger image
SeekIC No. : 004301601 Detail

BR8005: Features: ·Surge overload rating -200 amperes peak·Low forward voltage drop·Small size; simple installation·Sliver plated copper leads·Mounting position: AnySpecifications RATING SYMBOL BR800...

BR8005 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
BR8005
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/8

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

·Surge overload rating -200 amperes peak
·Low forward voltage drop
·Small size; simple installation
·Sliver plated copper leads
·Mounting position: Any


Specifications

RATING SYMBOL BR8005 BR801 BR802 BR804 BR806 BR808 BR810 UNITS
Maximum Recurrent Peak Reverse Voltage VRRM 50 100 200 400 600 800 1000 V
Maximum RMS Voltage VRMS 35 70 140 280 420 560 700 V
Maximum Average Forward Current Ta =50 I(AV) 8 A
Maximum Peak Forward Surge Current,
8.3ms Single half sine wave
Superimposed on rated load (JEDEC Method)		 IFSM 200 A
Peak Forward Voltage at 16.0A DC VF 1.0 V
Maximum DC Reverse Current @ Tj=25
at Rated DC Blocking Voltage @ Tj=100		 IR 10
1.0		 A
mA
Operating junction temperature range(Note3) TJ -55 to + 125
Storage Temperature Range TSTG -55 to + 150
