BP06VRPC-10A Picture
See larger image
SeekIC No. : 004300955 Detail

BP06VRPC-10A: Features: • Nonisolated• Industry standard pinout• Fixed frequency• High efficiency means less power dissipation• Optimized for cost• Remote on/off• Undervo...

BP06VRPC-10A Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
BP06VRPC-10A
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• Nonisolated
• Industry standard pinout
• Fixed frequency
• High efficiency means less power dissipation
• Optimized for cost
• Remote on/off
• Undervoltage lockout
• Over current and short circuit protection


Application

• Telecommunications
• Networking
• Computers and peripherals


Specifications

Parameter Symbol Min Typical Max Unit
Continuous Input Voltage Vin -0.3   15 V
Output Enable Terminal Voltage Vouten -0.3   15 V
Ambient Temperature Tamb 0   70
Storage Temperature Tstor -40   100


Note: Use beyond the maximum ratings may cause a reliability degradation of the DC/DC converter or may permanently damage the device.




Description

The Bel VRPC-10A series modules are non-isolated, step down DC/DC power converters that operate from a nominal 12V source. These converters are available in a range of output voltages from 1.5V to 3.3V. They are packaged in an industry standard single-in-line footprint and provide a maximum 10A output. Standard features of BP06VRPC-10A include remote on/off, over current protection and output voltage adjust. Remote sense is an optional feature. The BP06VRPC-10A may be used almost anywhere low-voltage silicon is employed and a 12V source is available. Typical applications include file servers, routers, line cards and other computing and communications equipment.
