Product Details

Description



Features:

* multi-base structure and emitter-ballasting resistors for an optimum temperature profile
* gold metallization ensures excellent reliability.
* internal matching to achieve an optimum wideband capability and high power gain.


Pinout

Connection Diagram


Specifications

Collector-base voltage (open emitter)peak value VCBOM  max. 36v
Collector-emitter voltage (open base) Vceo  max. 16,5v
Emitter-base voltage (open collector)  Vebo  max. 4v
Collector current
d.c. or average    IC  max. 6 A
(peak value); f > 1 MHz   ICM  max. 18 A
Total power dissipation
f > 1 MHz; Tmb = 25 °C   Ptot (r.f.) max. 65 W
Storage temperature  Tstg              -65 to , 150 °C
Operating junction temperature  Tj  max.  200 °C



Description

N-P-N silicon planar epitaxial transistor BLU20/12 primarily intended for use in mobile radio transmitters in the 470 MHz communications band.
