BFB1432S

DescriptionThe BFB1432S is designed as one kind of very small, low cost, filter device that is intended for use with A-D and D-A composite NTSC video converters using a sample rate of 4 x sub-carrier frequency. And this device is slower than often recommended to reduce time domain ringing. The ab...

product image

BFB1432S Picture
SeekIC No. : 004299608 Detail

BFB1432S: DescriptionThe BFB1432S is designed as one kind of very small, low cost, filter device that is intended for use with A-D and D-A composite NTSC video converters using a sample rate of 4 x sub-carrie...

floor Price/Ceiling Price

Part Number:
BFB1432S
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/25

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Description

The BFB1432S is designed as one kind of very small, low cost, filter device that is intended for use with A-D and D-A composite NTSC video converters using a sample rate of 4 x sub-carrier frequency. And this device is slower than often recommended to reduce time domain ringing.

The absolute maximum ratings of the BFB1432S can be summarized as:(1)Filter Shape: Lowpass;(2)Passband Shape: Flat;(3)Sampling Frequency: 14.32 MHz;(4)Insertion Loss at 100 kHz: < 1.5 dB;(5)End Of Passband: 5.51 MHz;(6)Passband Amplitude Ripple: 0.1 dB max;(7)Loss at half S.F.: 12 dB +/- 2 dB;(8)Start Of Stopband: 9.12 MHz;(9)Stopband Attenuation: 40 dB min;(10)Delay Time at 200 kHz: 188 ns +/- 5 ns;(11)Pulse and bar: K - rating is 1%;(12)Impedance: 75 ohms;(13)Temperature Range: 0°C to 70°C;(14)Aqueous Washable: Yes. If you want to know more information such as the electrical characteristics about the BFB1432S, please download the datasheet in www.seekic.com or www.chinaicmart.com.
