Configuration : | Single | Transistor Polarity : | NPN |
Collector- Emitter Voltage VCEO Max : | 55 V | Emitter- Base Voltage VEBO : | 12 V |
Collector- Base Voltage VCBO : | 80 V | Maximum DC Collector Current : | 0.5 A |
Maximum Collector Cut-off Current : | 0.05 uA | Maximum Operating Temperature : | + 150 C |
Mounting Style : | SMD/SMT | Package / Case : | SOT-54 |
Packaging : | Reel |
Rating | Symbol |
Value |
Units |
CollectorEmitter Voltage | VCEO |
55 |
Vdc |
CollectorBase Voltage | VCBO |
80 |
Vdc
|
Emitter-Base Voltage | VEBO |
12 |
Vdc |
Collector Current - Continuous | IC |
1.0 |
Adc |
Base Current | IB |
0.5 |
Adc |
Total Device Dissipation@ TA = 25 Derate above 25 |
PD |
625 5.0 |
Watt mW/ |
Total Device Dissipation @ TC = 25 Derate above 25 |
PD |
1.5 12 |
Watt mW/ |
Operating and Storage Junction Temperarture Range |
TJ:TSTG |
55 to +150 |
The BC618 is designed as one kind of darlington transistors and produced by MOTOROLA.The absolute maximum ratings of the BC618 can be summarized as:(1)collector-emitter voltage:55 Vdc;(2)collector-base voltage:80 Vdc;(3)emitter-base voltage:12 Vdc;(4)collector current-continuous:1.0 Adc;(5)total device dissipation @ TA=25°C:625 mW;(6)derate above 25°C:5.0 mW/°C;(7)total device dissipation @ TC=25°C:1.5 watts;(8)derate above 25°C:12 mW/°C;(9)operating and storage junction temperature range:-55 to +150°C.
The thermal characteristics of the BC618 are:(1)thermal resistance,junction to ambient:200°C/W;(2)thermal resistance,junction to case:83.3°C/W.If you want to know more information such as the electrical characteristics about the BCM4500KQMG,please download the datasheet in www.seekic.com or www.chinaicmart.com .
Motorola BC618 reserves the right to make changes without further notice to any products herein. Motorola BC618 makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does Motorola BC618 assume any liability arising out of the application or use of any product or circuit,and specifically disclaims any and all liability, including without limitation consequential or incidental damages.
Technical/Catalog Information | BC618 |
Vendor | ON Semiconductor |
Category | Discrete Semiconductor Products |
Transistor Type | NPN - Darlington |
Voltage - Collector Emitter Breakdown (Max) | 55V |
Current - Collector (Ic) (Max) | 1A |
Power - Max | 625mW |
DC Current Gain (hFE) (Min) @ Ic, Vce | 10000 @ 200mA, 5V |
Vce Saturation (Max) @ Ib, Ic | 1.1V @ 200A, 200mA |
Frequency - Transition | 150MHz |
Current - Collector Cutoff (Max) | 50nA |
Mounting Type | Through Hole |
Package / Case | TO-92-3, TO-226AA (Straight Leads) |
Packaging | Bulk |
Drawing Number | * |
Lead Free Status | Contains Lead |
RoHS Status | RoHS Non-Compliant |
Other Names | BC618 BC618 BC618OS ND BC618OSND BC618OS |
