BC237: Transistors Bipolar (BJT) NPN 45V 100mA HFE/8

BC237 Data Sheet

Get Latest Price

Part Number:: BC237
Mfg:: Fairchild Semiconductor
Supply Ability:: 5000

Price Break

Qty
1~5000

Unit Price
Negotiable

Processing time
15 Days

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/11/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

BC237_J35Z evaluate
Transistors Bipolar (BJT) NPN GENERAL PURPOSE
BC237_Q evaluate
Transistors Bipolar (BJT) NPN 45V 100mA HFE/8
BC237A evaluate
Transistors Bipolar (BJT) NPN 45V 100mA HFE/22

Product Details

Quick Details

Transistor Polarity :	NPN	Collector- Emitter Voltage VCEO Max :	45 V
Emitter- Base Voltage VEBO :	6 V	Maximum DC Collector Current :	0.1 A
DC Collector/Base Gain hfe Min :	120	Configuration :	Single
Maximum Operating Frequency :	250 MHz	Maximum Operating Temperature :	+ 150 C
Mounting Style :	Through Hole	Package / Case :	TO-92
Packaging :	Bulk

Description

Transistor Polarity : NPN
Configuration : Single
Maximum Operating Temperature : + 150 C
Emitter- Base Voltage VEBO : 6 V
Mounting Style : Through Hole
Package / Case : TO-92
Collector- Emitter Voltage VCEO Max : 45 V
Maximum DC Collector Current : 0.1 A
Maximum Operating Frequency : 250 MHz
Packaging : Bulk
DC Collector/Base Gain hfe Min : 120

Specifications

Symbol	Parameter		Value	Units
VCES	Collector-Emitter Voltage	: BC237 : BC238/239	50 30	V V
VCEO	Collector-Emitter Voltage	:BC237 : BC238/239	45 25	V V
VEBO	Emitter-Base Voltage	:BC237 : BC238/239	6 5	V V
I_C	Collector Current (DC)		100	mA
P_C	Collector Power Dissipation		500	mW
T_J	Junction Temperature		150	°C
T_STG	Storage Temperature		- 55 ~ 150	°C

Parameters:

Technical/Catalog Information	BC237
Vendor	Fairchild Semiconductor
Category	Discrete Semiconductor Products
Transistor Type	NPN
Voltage - Collector Emitter Breakdown (Max)	45V
Current - Collector (Ic) (Max)	100mA
Power - Max	500mW
DC Current Gain (hFE) (Min) @ Ic, Vce	120 @ 2mA, 5V
Vce Saturation (Max) @ Ib, Ic	200mV @ 500A, 10mA
Frequency - Transition	250MHz
Current - Collector Cutoff (Max)	15nA
Mounting Type	Through Hole
Package / Case	TO-92
Packaging	Bulk
Drawing Number	*
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	BC237 BC237
