BAT54TW-7-F: Schottky (Diodes & Rectifiers) 30V 200mW

BAT54TW-7-F Data Sheet

US $ .11~.32 / Piece | Get Latest Price

Part Number:: BAT54TW-7-F
Mfg:: Diodes Inc.
Supply Ability:: 5000

Price Break

Qty
0~1
1~10
10~100
100~250

Unit Price
$.32
$.22
$.15
$.11

Processing time
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/11/23

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

BAT54 evaluate
US $.03 - .1 / Piece

Schottky (Diodes & Rectifiers) SOT-23 30V 200mA
BAT54 /T3 evaluate
Schottky (Diodes & Rectifiers) DIODE SCHTKY TAPE-11
BAT54(Z) evaluate
PinoutSpecifications Part Number BAT54(Z) Power Rating (mW) 330 Peak Repetitive Revers...

Product Details

Quick Details

Product :	Schottky Diodes	Peak Reverse Voltage :	30 V
Forward Continuous Current :	0.2 A	Max Surge Current :	0.6 A
Configuration :	Triple Parallel	Recovery Time :	5 ns
Forward Voltage Drop :	1 V at 0.1 A	Maximum Reverse Leakage Current :	2 uA at 25 V
Maximum Power Dissipation :	200 mW	Operating Temperature Range :	- 65 C to + 125 C
Mounting Style :	SMD/SMT	Package / Case :	SOT-363
Packaging :	Reel

Description

Mounting Style : SMD/SMT
Product : Schottky Diodes
Peak Reverse Voltage : 30 V
Packaging : Reel
Maximum Power Dissipation : 200 mW
Forward Continuous Current : 0.2 A
Operating Temperature Range : - 65 C to + 125 C
Recovery Time : 5 ns
Max Surge Current : 0.6 A
Maximum Reverse Leakage Current : 2 uA at 25 V
Package / Case : SOT-363
Configuration : Triple Parallel
Forward Voltage Drop : 1 V at 0.1 A

Parameters:

Technical/Catalog Information	BAT54TW-7-F
Vendor	Diodes Inc (VA)
Category	Discrete Semiconductor Products
Diode Type	Schottky
Diode Configuration	3 Independent
Voltage - DC Reverse (Vr) (Max)	30V
Current - Average Rectified (Io) (per Diode)	200mA (DC)
Voltage - Forward (Vf) (Max) @ If	1V @ 100mA
Current - Reverse Leakage @ Vr	2A @ 25V
Reverse Recovery Time (trr)	5ns
Speed	Small Signal =< 200mA (Io), Any Speed
Mounting Type	Surface Mount
Package / Case	SC-70-6, SC-88, SOT-323-6, SOT-363
Packaging	Digi-Reel?
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	BAT54TW 7 F BAT54TW7F BAT54TW FDIDKR ND BAT54TWFDIDKRND BAT54TW-FDIDKR
