BAT54SFILM: Schottky (Diodes & Rectifiers) 300mA 40V VRRM 7pF -65 to 150 C

BAT54SFILM Data Sheet

US $ .05~.1 / Piece | Get Latest Price

Part Number:: BAT54SFILM
Mfg:: STMicroelectronics
Supply Ability:: 5000

Price Break

Qty
0~1
1~10
10~100
100~250

Unit Price
$.1
$.06
$.06
$.05

Processing time
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/11/27

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

BAT54 evaluate
US $.03 - .1 / Piece

Schottky (Diodes & Rectifiers) SOT-23 30V 200mA
BAT54 /T3 evaluate
Schottky (Diodes & Rectifiers) DIODE SCHTKY TAPE-11
BAT54(Z) evaluate
PinoutSpecifications Part Number BAT54(Z) Power Rating (mW) 330 Peak Repetitive Revers...

Product Details

Quick Details

Product :	Schottky Diodes	Peak Reverse Voltage :	40 V
Forward Continuous Current :	0.3 A	Max Surge Current :	1 A
Configuration :	Dual Series	Recovery Time :	5 ns
Forward Voltage Drop :	0.9 V at 0.1 A	Maximum Reverse Leakage Current :	1 uA at 30 V
Operating Temperature Range :	- 40 C to + 150 C	Mounting Style :	SMD/SMT
Package / Case :	SOT-23	Packaging :	Reel

Description

Maximum Power Dissipation :
Mounting Style : SMD/SMT
Product : Schottky Diodes
Packaging : Reel
Operating Temperature Range : - 40 C to + 150 C
Max Surge Current : 1 A
Peak Reverse Voltage : 40 V
Package / Case : SOT-23
Configuration : Dual Series
Forward Continuous Current : 0.3 A
Recovery Time : 5 ns
Forward Voltage Drop : 0.9 V at 0.1 A
Maximum Reverse Leakage Current : 1 uA at 30 V

Parameters:

Technical/Catalog Information	BAT54SFILM
Vendor	STMicroelectronics (VA)
Category	Discrete Semiconductor Products
Diode Type	Schottky
Diode Configuration	1 Pair Series Connection
Voltage - DC Reverse (Vr) (Max)	40V
Current - Average Rectified (Io) (per Diode)	300mA (DC)
Voltage - Forward (Vf) (Max) @ If	900mV @ 100mA
Current - Reverse Leakage @ Vr	1A @ 30V
Reverse Recovery Time (trr)	5ns
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Mounting Type	Surface Mount
Package / Case	SOT-23-3
Packaging	Digi-Reel?
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	BAT54SFILM BAT54SFILM 497 2522 6 ND 49725226ND 497-2522-6
