B25673A4332A040

Operating Temperature Range :
Lead Spacing :
Dielectric : Polypropylene (PP)
Product Type : Power Factor
Tolerance : - 5 %, + 10 %
Termination Style : Quick Connect
Dimensions : 136 mm Dia. x 200 mm L
Series : MKK400 B25673
Voltage Rating : 440 Volts
Capacitance : 181 uF x 3


Description

The B25673A4332A040,(1)Film Capacitors Power Factor Correction ; (2)PhaseCap Compact capacitors .

Features of the B25673A4332A040 are:(1)Dielectric: Polypropylene film ; (2)Non PCB, semi-dry biodegradable resin ; (3)Wave cut ; (4)Extruded round aluminum can with stud ; (5)Provided with ceramic discharge module ; (6)Overpressure disconnector ; (7)Three-phase, delta connected ; (8)Self-healing technology ; (9)Naturally air cooled (or forced air cooling)  ; (10)Indoor mounting   ; (11)For Power Factor Correction ; (12)Optimized PFC-capacitor terminal ; (13)Threaded stud at bottom of can (max. torque for M12 = 10 Nm) .
