SeekIC No. : 00195126 Detail

B160-13: Schottky (Diodes & Rectifiers) 60V 1A

B160-13 Data Sheet

Get Latest Price

Part Number:: B160-13
Mfg:: Diodes Inc.
Supply Ability:: 5000

Price Break

Qty
1~5000

Unit Price
Negotiable

Processing time
15 Days

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/11/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

B160 evaluate
Specifications Product Type Schottky Part Number B160 Max Average Rectified Current...
B160/B evaluate
Features: Guard Ring Die Construction for Transient ProtectionIdeally Suited for Automatic Assembl...
B160-13-F evaluate
US $.12 - .34 / Piece

Schottky (Diodes & Rectifiers) 60V 1A

Product Details

Quick Details

Product :	Schottky Diodes	Peak Reverse Voltage :	60 V
Forward Continuous Current :	1 A	Max Surge Current :	30 A
Configuration :	Single	Forward Voltage Drop :	0.7 V
Maximum Reverse Leakage Current :	500 uA	Operating Temperature Range :	- 65 C to + 150 C
Mounting Style :	SMD/SMT	Package / Case :	SMA
Packaging :	Reel

Description

Recovery Time :
Maximum Power Dissipation :
Configuration : Single
Mounting Style : SMD/SMT
Product : Schottky Diodes
Packaging : Reel
Maximum Reverse Leakage Current : 500 uA
Max Surge Current : 30 A
Operating Temperature Range : - 65 C to + 150 C
Forward Continuous Current : 1 A
Peak Reverse Voltage : 60 V
Package / Case : SMA
Forward Voltage Drop : 0.7 V

Parameters:

Technical/Catalog Information	B160-13
Vendor	Diodes Inc
Category	Discrete Semiconductor Products
Diode Type	Schottky
Voltage - DC Reverse (Vr) (Max)	60V
Current - Average Rectified (Io)	1A
Voltage - Forward (Vf) (Max) @ If	700mV @ 1A
Reverse Recovery Time (trr)	-
Current - Reverse Leakage @ Vr	500A @ 60V
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Mounting Type	Surface Mount
Package / Case	DO-214AC, SMA
Packaging	Tape & Reel (TR)
Capacitance @ Vr, F	110pF @ 4V, 1MHz
Lead Free Status	Contains Lead
RoHS Status	RoHS Non-Compliant
Other Names	B160 13 B16013 B160DITR ND B160DITRND B160DITR
